Portable Screw Air Compressor

Portable screw air compressor is a kind of water-cooled air compressor. Our portable screw air compressors feature reasonable structure, compact design, low noise, and energy efficiency, and easy transfer and maintenance.

Our Portable Screw Air Compressor is Designed with Auto-stop Function in Case of Following Situations
1. The exhaust temperature from the air end is extremely high.
2. The air supplied by compressor is extremely high.
3. The water temperature of diesel engine is extremely high.
4. The engine oil pressure in the diesel engine is extremely low.
5. The water level of diesel engine is extremely low.
6. The oil level of diesel engine is extremely low.

Features of Portable Screw Air Compressor
1. Easy to operate.
2. Integrated control panel.
3. Designed with auto-stop protection system
4. Auto air valve
5. Our screw air compressor is designed with oil level detectoscope

Bottom

Strong Adaptability to Different Environments
6. Designed with cold box, our portable screw air compressor can work normally at a high temperature of 25℃
7. The cold start device makes our screw compressors capable of working at -23℃
8. High speed running device (≤60KM/h)
9. Environmental friendly and low noise (≤75dBA)
10. Covered with the latest powder coating

Technical Parameters

Diesel Portable Driven Screw Air Compressor Motor Driven Portable Screw Air Compressor

1. Diesel Portable Driven Screw Air Compressor

Model	XR135 WCU	XR185 WCU	R265 WCU	VHR300 WCU	HR365 WCU	XR375 WCU	R425 WCU	VHR425 WCU	HR500 WCU	R650 WCU
Stage	Single stage compression
Capacity	3.8	5.2	7.5	8.5	10.3	10.6	12	12	14	18.5
Working pressure	7	7	7	13.8	10.3	8.6	7	13.8	10.3	7
Fuel tank volume	25	40	60	120	120	120	120	180	180	180
Engine model	BT 1.9-C	2BT 2.9-C	4BT 3.9-C	6BT 5.9-C	6BT 5.9-C	6BT 5.9-C	6BT 5.9-C	6CT 8.3-C	6CT 8.3-C	6CT 8.3-C
Engine power	30	48	60	97	97	97	97	145	145	145
fuel cooling method	Diesel Engine Water Cooled	Diesel Engine Water Cooled	Diesel Engine Water Cooled	Diesel Engine Water Cooled	Diesel Engine Water Cooled	Diesel Engine Water Cooled	Diesel Engine Water Cooled	Diesel Engine Water Cooled	Diesel Engine Water Cooled	Diesel Engine Water Cooled
Rotating speed	2400	2500	2200	2000	2000	2000	2000	1800	1800	1800
Electric system voltage	24	24	24	24	24	24	24	24	24	24
Oil remain	<10
Connection qty	13"	15"	1-11/2"	1-1" 1- 11/2"	1-1" 1- 11/2"	1-1" 1- 11/2"	1-1" 1-11/2"	1-1" 1- 11/2"	1-1" 1- 11/2"	1-1" 1- 11/2"
Connection size	13"	15"	1-11/2"	1-1" 1- 11/2"	1-1" 1- 11/2"	1-1" 1- 11/2"	1-1" 1-11/2"	1-1" 1- 11/2"	1-1" 1- 11/2"	1-1" 1- 11/2"
Tyre qty	2X5.50-8			2X7.50-12
Tyre specification	2X5.50-8			2X7.50-12
Length	2735	2735	2735	3900	3900	3900	3900	4600	4600	4600
Width	1705	1705	1705	1980	1980	1980	1980	2040	2040	2040
Height	1800	1800	1800	1950	1950	1950	1950	1980	1980	1980
Shipping weight	916	966	1350	2000	2000	2000	2000	3200	3200	3200

Model	VHR600WCU	XR750WCU	VHR750WCU	HR900WCU	RHR750WCU	SHR825WCU	RHR1070WCU
Stage	Single stage compression				Two stages compression
Capacity	17	21．2	21.2	25.5	21.2	23.3	30.0
Working pressure	13.8	8.6	13.8	10.3	20.7	17.2	24.0
Fuel tank volume	320	320	360	360	360	360	480
Engine model	6CT8.3-C	6CT8.3-C	6LTAA8.9-C	6LTAA8.9-C	6LTAA8.9-C	6LTAA8.9-C	6LTAA9.8-C
Engine power	179	178	239	239	260	260	348
fuel cooling method	Diesel Engine Water Cooled	Diesel Engine Water Cooled	Diesel Engine Water Cooled	Diesel Engine Water Cooled	Diesel Engine Water Cooled	Diesel Engine Water Cooled	Diesel Engine Water Cooled
Rotating speed	1800	1800	1800	1800	1800	1800	1800
Electric system voltage	24	24	24	24	24	24	24
Oil remain	<10
Connection qty	1-11/2" 1-2"	1-11/2" 1-2"	1-11/2" 1-2"	1-11/2" 1-2"	1-11/2" 1-2"	1-11/2" 1-2"	2-21/2"
Connection size	1-11/2" 1-2"	1-11/2" 1-2"	1-11/2" 1-2"	1-11/2" 1-2"	1-11/2" 1-2"	1-11/2" 1-2"	2-21/2"
Tyre qty	4X7.50-16
Tyre specification	4X7.50-16
Length	5200	5200	5200	5200	5200	5200	5500
Width	1960	1960	2060	2060	2060	2060	2300
Height	2300	2300	2480	2480	2480	2480	2500
Shipping weight	3800	3800	5600	5600	5600	5600	6800

Designs and specifications are subject to change without prior notice.
Notes: Capacity tested according to ISO2151: 2004 appendix C standard
Noise level tested according to ISO1217 appendix C1996 (CAGI-pneurop PN2CPT2)

We are a primary China-based manufacturer and supplier of portable screw air compressors. We specialize in producing screw compressors, oilless air compressors, piston compressors, centrifugal air compressors, etc. These products are of superior quality and competitive prices, and they have been exported to over 120 countries and regions, including the USA, Canada, Russia, the United Kingdom, Germany, Australia, Brazil, Saudi Arabia, etc.
Thank you very much for your visit of our website. More information concern about our air compression machines are provided on the product page and you can contact us directly. Shanghai Xinran Compressor Company will satisfy all your need.
