Hydrogen Compressor

Hydrogen Filling and Hydrogenation Station Compressors

氢气充装压缩机+加氢站压缩机

Designed for high-pressure hydrogen handling, hydrogen filling and hydrogenation station compressors are used for hydrogen transfer, filling, and boosting applications. This series is built for demanding operating conditions where capacity, gas purity, and automation are all important, making it suitable for hydrogen infrastructure and related industrial projects.

Request a Quote
Features
  • Large capacity, heavy-duty configuration
    A single compressor can deliver up to 2000 Nm³/h, with piston force up to 250 kN, making it suitable for higher-capacity hydrogen compression duties.
  • Clean compression with leakage control
    For high-purity gas applications, a diaphragm compressor can be used to keep the compression medium free from contamination while helping prevent leakage during the compression process.
  • High-level automation
    The system can be configured for one-button automatic start and stop, supporting highly automated operation and, where required, unattended running.
Applications

    This hydrogen filling and hydrogenation station compressor delivers a practical solution for projects that require reliable hydrogen compression, such as:

  • Hydrogen boosting at refueling stations
  • Hydrogen filling for tube trailers and cylinders
  • High-pressure hydrogen transfer

Technical Data
Piston Force (kN) 800 500 320 250 160 100 65 45 30
Compressed Gas Hydrogen, nitrogen, natural gas, ethylene, propylene, coal gas, hydrogen chloride, hydrogen fluoride, carbon dioxide, chloromethane, carbon monoxide, acetylene hydrogen mixtures, monochloromethane, difluoromethane, tetrafluoroethylene, pentafluoroethane, hexafluoropropylene, etc.
Discharge Pressure MPa(G) ≤25 ≤30
Compression Stages 1-4 stages 1-6 stages 1-3 stages
Number of Rows 2-4 2-6 1-4
Arrangement M/D M/D M/D M/D M/D M/D/P M/D/P M/D/L/P L/P
Stroke (mm) 280-360 240-320 180-240 200
Rotational Speed (rpm) 300-375 333-450 375-585 420-485
Max Motor Power (kW) 5600 3600 3300 2700 12500 800 560 250 75
Mounting Type Non-skid Non-skid / skid-mounted Skid-mounted
Digital Simulation Design Yes
Pulsation Calculation Yes
Process Inspection Chemical composition, mechanical properties, flaw detection, hydrostatic testing, and gas tightness testing
Factory Testing No-load mechanical running test according to the quality plan
Site Acceptance 72-hour acceptance test under actual operating conditions
Applicable Industry Petrochemical, silicon, fluorochemical, hydrogen energy, metallurgy, pharmaceutical, aerospace, nuclear power, etc.
